12 Mm Rear Thru-Axle

The Wolf Tooth Components 12 mm thru-axle for rear wheels is available in different lengths and with different thread pitches.
Technical Information:Use:rear: 12 x 142 mm, 12 x 148 mmType:thru-axleAxle Material:aluminium (7075-T6)Nominal Diameter:M12Features:with fixed stainless steel washer, protects the forkstiffer interface, protection against jamming5 and 6 mm hex fittingMade in the USA
Note from the manufacturer:Always apply a small amount of grease to the washer and thread before installation.Models:Type 1:
Axle Length:166 mmThread Pitch:1.75Thread Length:20 mmManufacturer Number:AXLE12166175
Type 2:
Axle Length:167 mmThread Pitch:1.0Thread Length:16.5 mmManufacturer Number:AXLE12167100
Type 3:
Axle Length:172 mmThread Pitch:1.5Thread Length:13 mmManufacturer Number:AXLE12172150
Type 4:
Axle Length:173 mmThread Pitch:1.0Thread Length:16.5 mmManufacturer Number:AXLE12173100
Type 5:
Axle Length:174 mmThread Pitch:1.75Thread Length:20 mmManufacturer Number:AXLE12174175
Type 6:
Axle Length:178 mmThread Pitch:1.5Thread Length:13 mmManufacturer Number:AXLE12178150
Type 7:
Axle Length:180 mmThread Pitch:1.75Thread Length:17 mmManufacturer Number:AXLE12180175
Type 8:
Axle Length:187 mmThread Pitch:1.5Thread Length:20 mmManufacturer Number:AXLE12187150
Type 9:
Axle Length:192 mmThread Pitch:1.75Thread Length:17 mmManufacturer Number:AXLE12192175
Type 10:
Axle Length:198 mmThread Pitch:1.75Thread Length:17 mmManufacturer Number:AXLE12198175Contents:1 x Wolf Tooth Components 12 mm thru-axle
